Spesifikasi
Cutting Speed: 300mm / s
Format Graphic Supported: AI, BMP, DST, DWG, DXF, DXP, PLT
Aplikasi: Laser Cutting
Kawontenan: Anyar
Cutting Thickness: 0.5-25mm
CNC or Not: Ya
Mode Pendinginan: Cooling Banyu
Kontrol Perangkat Lunak: Cypcut
Papan Asal: Anhui, China (Dharatan)
Jenama: ACCURL
Sertifikasi: CE, ISO, SGS, FDA
Laser Power: 500W, 700W, 1KW, 1500W, 2KW, 3KW, 4KW
Sumber Laser: IPG, ROFIN, SPI, MAX
Mode Driving: pinion & rack
Akurasi Posisi: 0,03mm
Opsional Parts: sistem bantu tambahan, udara con
Power Supply: 380V / 50Hz (60Hz)
Konsumsi Daya: 8KW-20KW
Layanan Sawise Sales: Engineers kasedhiya kanggo mesin jaban rangkah
Tipe Laser | Serat Laser Generator | ||
Wilayah Kerja (L * W) | 3000 * 1500mm | 4000 * 1500mm | 4000 * 2000mm |
Laser Wavelength | 1060 nm | ||
Rated Output Power | 500W / 700W / 800W / 1000W / 1500W / 2000W / 3000 (Opsional) | ||
Beam Quality | <0.373mrad | ||
X axis Travel Distance | 2550mm | 4550mm | 6050mm |
Y axis Travel Distance | 1325mm | 1525mm | 1525mm |
Z axis Travel Distance | 120mm | ||
Mode Pendinginan | Air Cooling | ||
Akurasi Posisi Aksial | ≤ ± 0,05mm / m | ||
Baleni Ketepatan Positioning | ≤ ± 0,03mm / m | ||
Voltase Kerja | 3 phase 380V / 50Hz-60Hz | ||
Tingkat Daya Pangreksan Umum | IP54 | ||
Maksimum Cutting Speed | 20m-80m / min | ||
Watesan Line Minimal | 0.1mm-0.2mm | ||
Mupangat Tebuka Maksimum | 4mm / 6mm / 8mm / 10mm / 16mm | ||
Ukuran (L * W * H)) | 8000 * 3000 * 2000mm | 10000 * 3000 * 2000mm | 10000 * 3500 * 2000mm |
Kualitas
Pabrik produksi modern lan pameran modern ing Cina. CE SGS lan ISO certified. Mesin dititi priksa dening collimator laser tliti kanggo njamin flatness lan vertikal. Saben mesin bakal dites tenan sadurunge ngirim metu.
Layanan Kita
Layanan Penjualan Profesional
* Enquiry and consulting support.
* Sample testing support.
* Ndeleng Pabrik kita.
Sawise Sales Service
* Warranty: Sakumpulan garansi mesin sakjamone setahun, babar pisan diperpanjang.
* Sawise-Sales Layanan: We offer manual, video, panuntun dhumateng online lan remot pitulungan. Teknisi siap tampil ing panggonan sampeyan kanggo instalasi lan latihan. Sampeyan uga bisa ngirim operator menyang pabrik kanggo latihan.
